This allows for more flexibility with regards to the number of different parts you can machine on the S.A.H.’s. Or, we can design a system that has removable fixture plates. First, we can design a system that is dedicated to one particular part or family of parts. There are two design options with the S.A.H. This small cycle time increase is far out weighted by the elimination of errors/problems the S.A.H. Actuating and releasing the pressure does increase your part cycle by (7– 9) seconds. At the end of your machining cycle you tool change back and release the hydraulic pressure. Then you tool change and proceed with your machining cycle.
#Plate rack galleried spindles driver#
During your machining cycle, with the first tool, a special driver (supplied by Kirsan) is used to engage the S.A.H. This eliminates the need to rely on the machinist to connect hoses, de-pressurize, activate pumps or valves. unit houses a hydraulic pump, valves and reservoir which eliminates the need for any external hydraulic power supply. Run the hydraulic pressure to high and distort your partĪll of these thing have happened at our shop at one time or another and that is why Kirsan designed and manufactured the S.A.H.Not running the hydraulic pressure up high enough and having your parts move.Forget to remove the hydraulic hose from the fixture before it moves into the machine.Forget to close or open the valve while activating the external pump.Forget to power up the fixture before it moves into the machine.Has any of the following ever happened in your shop? units will give you peace of mind knowing that your fixture is fully charged and your parts are clamped at the same pressure each and every time. This design eliminates the need to hydraulically couple, actuate, monitor pressures, and un-couple during loading and unloading of parts onto your fixtures. Kirsan Engineering's Spindle Actuated Hydraulics (S.A.H.) eliminates human error and the requirement of an external hydraulic source.
